Washing capacity
600 dishes / hour | 1000 cups / hour
Number of people
30-300
Applicable place
Small dining room, restaurant, hotel and so on.
Applicable place
Covers little area, no more than 1 sqm
Can be simply operated by only 1 people
Technical Parameters技术参数：
Dimension (L*W*H) (mm) 外形尺寸 | 715*815*1510mm / 650*700*1340mm |
Rated Voltage 额定电压 | 380V/50Hz |
Rated Power 额定功率 | 15.8KW / 12.8KW |
Main Heating Power 主加热功率 | 3KW |
Main Wash Pump Power 清洗泵功率 | 0.73KW |
Rinse Heating Power 冲洗加热功率 | 12KW |
Rinse Pump Power 冲洗泵功率 | 0.125KW |
Water Tank Capacity (L) 水箱容量 | 22L/18L |
Heat Tank Capacity (L) 加热箱容量 | 12L/11L |
Power Line specifications (mm²) 电线规格 | 5*6mm² |
Electric Current (A) 电流 | 25A |
Water Inlet (DN) 进水口 | 3/4"-Φ10 |
Drainage (DN) 出水口 | 32 |
Water Pressure (kg/cm2) 水压 | 0.3~6 |
Water Main Wash Temperature (℃) 主水洗温度 | 55-65 |
Water Rinse Temperature (℃) 冲洗温度 | 78~90 |
Minimum Water Flow (L/H) 最小水流 | 150L |
Washing Cycle 清洗周期 | 60/90/120s |
Net Weight (kg) 净重 | 115, 100 |
Max Capacity (rack/hour) 最大效能 | 60 basket/ hour |
Dispenser (the pump for detergent) 分配器（洗涤剂泵） | optional |
